Description
| Specification | Details |
|---|---|
| Model | RDE691GKA54200 |
| Series | Radius E-Series |
| Engine | Kawasaki FR691V V-Twin |
| Power | 23 HP |
| Displacement | 726 cc / 44.3 cu in |
| Deck Width | 54 inches |
| Deck Type | Series 2+ fabricated & welded steel |
| Deck | Floating, side discharge |
| Blades | 3 × 18.75″ |
| Cutting Height | 1.5–5″ |
| Height Adjustment | 0.25″ increments |
| Transmission | 2 × Hydro-Gear ZT-2800 |
| Forward Speed | Up to 8 mph |
| Reverse Speed | Up to 5 mph |
| Fuel Capacity | 7 gallons |
| Front Tires | 13 × 6.5-5 |
| Rear Tires | 22 × 10-10 |
| PTO | Electromagnetic clutch |
| ROPS | 2-post foldable |
| Weight | 826 lb |
| Length | 83.9″ |
| Overall Width | 66.5″ |
| Overall Height | 73.7″ |
| Max Coverage | About 3.48 acres/hour |
