Description
| Specification | Details |
|---|---|
| Brand | MechMaxx |
| Model | DM8 |
| SKU | 150232 |
| Type | 3-Point Disc Mower |
| Working Width | 7.7 ft / approx. 92.4 in |
| Number of Discs | 6 |
| Number of Blades | 12 |
| Tractor Requirement | 50–100 HP |
| Minimum Tractor Weight | 2,000 lb |
| Hitch | Category 2, 3-point |
| PTO Speed | 540 RPM |
| Working Speed | 2.5–6.2 mph |
| Stubble Height | Approx. 2 in |
| Disc Diameter incl. blade | 19.7 in |
| Disc Length | 15.4 in |
| Tilt-Down Angle | 30°–40° |
| Tilt-Up Angle | 80° |
| Transmission | Fully gear-driven |
| PTO Shaft | 1.375″ Z6 spline |
| Belts | 4 |
| Blade Material | 65 Mn steel |
| Overall Size | 167 × 55 × 30 in |
| Shipping Size | 102 × 29 × 67 in |
| Net Weight | 1,191 lb |
| Gross Weight | 1,389 lb |
| Warranty | 1 year |
